VLX 100 Pivot Door

VLX 100 Pivot Door in Hollywood, FL | Sightline Windows & Doors Hollywood

The VLX 100 Pivot Door is the entry point Hollywood, FL homeowners and architects specify when a standard hinged door won’t do. Built by ViewLux and installed by Sightline Windows & Doors Hollywood as an authorized partner, this heavy-duty aluminum system rotates on a vertical center axis to support oversized glass panels that turn a doorway into a architectural statement. We’re talking about panels up to 60 inches wide and 120 inches tall, floating on precision hardware that makes the door feel weightless in operation. In Hollywood’s mix of mid-century modern revivals, new coastal contemporary builds, and commercial spaces along Young Circle and the beach corridor, the VLX 100 answers the demand for indoor-outdoor flow without sacrificing structural integrity. Sightline Windows & Doors Hollywood has measured, specified, and installed these systems across Broward County since opening our doors. Call (754) 714-7309 to schedule a free on-site measurement and see whether the VLX 100 fits your opening.

Call (754) 714-7309

Product Overview - VLX 100 Pivot Door

The VLX 100 is engineered around a simple idea: a door should pivot, not merely swing. Unlike conventional hinged doors that hang from a frame on one side, this system mounts on a vertical axis positioned at the door’s center or offset point, allowing the panel to rotate within its opening. The result is a broader walkthrough, cleaner sightlines, and a kinetic quality that draws the eye every time someone passes through.

ViewLux builds the VLX 100 from extruded aluminum with a 0.098-inch wall thickness and 2.56-inch profile width. That’s substantial material, not the thin-walled stock you see on budget imports. The aluminum accepts large glass lites without flexing or racking over time, which matters in Hollywood’s climate where thermal cycling and salt air test lesser materials. The frame accommodates single panels up to 60 inches wide by 120 inches tall, dimensions that would overwhelm a traditional hinge set but ride smoothly on the VLX 100’s pivot hardware.

Buyers choose this series for three reasons. First, the aesthetic: the minimal frame and expansive glass create the “disappearing wall” effect that architects prize. Second, the function: pivot hardware distributes weight to the floor and header more evenly than side hinges, reducing stress on the jamb. Third, the durability: the aluminum construction and stainless pivot mechanism resist the corrosion that degrades steel systems within a few years of Hollywood’s coastal exposure. Sightline Windows & Doors Hollywood specifies the VLX 100 for waterfront homes in Hollywood Beach, modern renovations in Emerald Hills, and commercial entries along Federal Highway where first impressions matter.

Technical Specifications

The 0.098-inch wall thickness puts this in heavy-duty territory, well above the 0.060-inch minimum common in residential aluminum. That extra material provides the rigidity needed for the 5-foot by 10-foot maximum span without adding the weight of steel. The 2.56-inch profile width balances structural depth with visual minimalism; wider profiles look clunky on contemporary homes, while narrower ones can’t handle the hardware loads.

Before

After

Performance Features

Thermal Efficiency

The VLX 100 incorporates a thermal break that separates interior and exterior aluminum surfaces, interrupting the conductive path that makes raw aluminum a poor insulator. NFRC-rated performance means the numbers are verified by independent testing, not claimed by the factory. In Hollywood’s cooling-dominated climate, this translates to lower air conditioning loads and reduced condensation risk on interior frame surfaces during humid mornings.

Acoustic Performance

Large glass panels can amplify street noise if the frame doesn’t dampen vibration. The VLX 100’s perimeter gasketing and laminated glass option (when specified) reduce sound transmission from Federal Highway traffic, A1A corridor activity, and neighboring properties. The pivot hardware itself operates silently, without the click or grind of worn hinges.

Airtightness & Weather Seal

Continuous compression seals at the head, jamb, and sill interfaces prevent uncontrolled air leakage. This matters beyond energy bills: in Hollywood’s humid subtropical climate, infiltrating outdoor air carries moisture that can condense on cool interior surfaces. The AAMA 812 low-expansion foam sealant we apply at all perimeter joints maintains seal integrity as the structure settles and seasons.

Waterproofing

The sill profile includes integrated drainage channels that direct wind-driven rain to the exterior. Sightline Windows & Doors Hollywood verifies proper slope and sealant continuity during installation; even the best-designed system leaks if the sill pan drains backward or the head flashing is omitted. We water-test every pivot door we install in Hollywood before signing off.

Wind Resistance

Florida’s wind-load requirements are among the strictest nationally, and Hollywood sits in a region where design pressures reflect hurricane exposure. The VLX 100’s frame depth, corner construction, and hardware anchoring are rated for these loads. When impact-resistant laminated glass is specified, the assembly meets the missile-impact and cyclic-pressure testing required for coastal installations.

Security & Hardware

The pivot mechanism includes multi-point locking that engages at the top and bottom of the panel, not just at a single latch point. Stainless steel pivot pins resist the corrosion that seizes lesser hardware. For Hollywood properties where owners split time between residences, this hardware reliability matters: a door that won’t lock or unlock because of salt corrosion is a security and convenience failure.

Color & Glass Options

The six finish options cover the full range of Hollywood architectural styles without requiring custom powder-coating lead times. Premium Black and Pure White dominate our local installations, black for the coastal contemporary homes going up east of the Intracoastal, white for the Mediterranean and traditional properties in Hollywood Lakes and Emerald Hills where lighter frames complement stucco and tile roofs. Anodized Silver reads industrial-modern and suits commercial entries or loft conversions. Bronze and Champagne offer warmth that softens the aluminum’s inherent coolness, appropriate for transitional designs. Teak Wood finish provides the grain pattern of tropical hardwood without the maintenance burden; in Hollywood’s sun and salt, real teak demands annual refinishing that most owners won’t commit to.

Glass selection depends on privacy, solar control, and safety priorities. Clear glass maximizes the transparency that makes pivot doors worth specifying. Frosted and Obscure options diffuse light while blocking sightlines, useful for bathrooms or bedrooms that open to courtyards. Low-E coatings reject infrared heat while passing visible light, the standard choice for west-facing Hollywood entries that take afternoon sun. Tempered glass is safety-rated and shatters into granular pieces rather than shards. Laminated glass adds the impact resistance required for hurricane zones and provides acoustic damping and forced-entry resistance. Sightline Windows & Doors Hollywood helps clients pair glass and finish selections to their specific opening orientation and use case.

Installation by Sightline Windows & Doors Hollywood in Hollywood

A ViewLux VLX 100 Pivot Door is only as good as its installation. The manufacturer warranty is explicit: improper installation voids coverage. That’s not boilerplate; pivot doors have zero tolerance for racked openings or out-of-level sills. The hardware binds, the seals gap, and the door that should feel effortless becomes a daily annoyance. Sightline Windows & Doors Hollywood installs every VLX 100 to AAMA 2400/2410 standards because we’ve seen what happens when shortcuts substitute for procedure.

Our process begins with a pre-installation inspection of the rough opening. We check dimensions against the shop drawings, verify structural support at the header for the pivot hardware loads, and confirm the sill substrate drains to the exterior. In Hollywood’s older homes, particularly the 1950s and 1960s stock near the beach, rough openings often need reframing to achieve the plumb, level, and square tolerances the pivot mechanism requires.

Setting the frame, we shim and anchor to maintain alignment within 1/8 inch across the full height and width. The pivot hardware is positioned precisely at the specified center or offset axis; a quarter-inch error at the floor magnifies to visible panel misalignment at the head. We apply AAMA 812 low-expansion foam sealant at all perimeter joints, the specific product and technique the standard requires for air and water barrier continuity. Backer rod and sealant follow at exterior joints.

After hardware adjustment and operation testing, we perform a water spray test that simulates wind-driven rain at the pressures relevant to Hollywood’s exposure. Only then do we clean the glass and frame, remove protective films, and walk the owner through operation and maintenance. The permit, if required for your Hollywood project, is pulled and closed with inspection passed.

Hollywood’s climate specifics inform our installation details. The salt air within a mile of the beach accelerates galvanic corrosion at dissimilar metal contacts; we isolate aluminum from steel anchors with appropriate barriers. The intense summer sun expands frame components differentially; we set clearances that accommodate movement without binding. These aren’t theoretical concerns. We’ve repaired doors installed by others who ignored them.

Frequently Asked Questions - VLX 100 Pivot Door

What is the lead time for the VLX 100 Pivot Door in Hollywood?

Lead time typically runs 8 to 12 weeks from signed approval of shop drawings, depending on glass and finish selection. Custom sizes within the maximum span, impact-rated laminated glass, and non-standard finishes extend toward the longer end. Standard configurations in Premium Black or Pure White with clear tempered glass tend toward the shorter. Call (754) 714-7309 to check current production schedules and reserve your slot.

Does the VLX 100 qualify for energy tax credits?

The NFRC-rated thermal break and Low-E glass options may contribute to whole-home energy performance improvements that qualify under federal or Florida-specific programs, but the door itself is not independently eligible as a standalone product credit. We provide certified performance data for your tax preparer or energy auditor. For current program details, call (754) 714-7309 and we’ll share what documentation we can supply.

What warranty comes with the Pivot Door?

ViewLux provides a limited lifetime warranty on the aluminum frame and finish, with 10 years on the pivot hardware and 5 years on the insulated glass unit seal, contingent on professional installation per AAMA standards. Sightline Windows & Doors Hollywood backs our installation workmanship with our own coverage. Warranty registration is completed at final inspection. Call (754) 714-7309 for complete terms.

Can I customize the size of my VLX 100 Pivot Door?

Yes, within the 60-inch width and 120-inch height maximums. Custom sizing is standard for pivot doors; few openings match stock dimensions, particularly in Hollywood’s varied housing stock from 1920s bungalows to new construction. We measure your rough opening, produce shop drawings for your approval, and factory-build to those dimensions. Call (754) 714-7309 to schedule measurement.

How do I maintain aluminum frames in Hollywood’s coastal climate?

Rinse frames quarterly with fresh water to remove salt accumulation, particularly on beachfront properties. Wash annually with mild detergent and soft cloth; avoid abrasive cleaners that scratch anodized or painted finishes. Lubricate pivot hardware annually with a silicone-based product, not petroleum grease that attracts grit. Inspect perimeter sealant every two years for cracks or separation. Call (754) 714-7309 if you notice operation changes or seal degradation; early attention prevents larger repairs.

Get a Quote - VLX 100 Pivot Door in Hollywood

Ready to see whether the VLX 100 Pivot Door fits your Hollywood project? Sightline Windows & Doors Hollywood provides free on-site measurements, detailed quotes with line-item pricing, and shop drawings for your approval before anything goes to fabrication. We’ll walk your opening, discuss glass and finish options suited to your architecture and orientation, and explain the installation timeline. No pressure, no deposit required to start the conversation. Call (754) 714-7309 or stop by to schedule your free estimate. We’ve installed ViewLux systems across Hollywood, from the beach to the Lakes, and we’ll put that experience to work on your door.

Written by the team at Sightline Windows & Doors Hollywood, serving Hollywood, FL as an authorized ViewLux installation partner.
